Servo Ventilator 300/300A Disassembling and assembling
E382 E380E 061 01 03 01 Siemens-Elema AB 97
Battery pole covers
• Make sure that the battery pole covers
are mounted on the battery poles
according to figure.
Assembling the pneumatic
section to the power section
The procedure for assembling the
pneumatic section to the power section is
the reverse of the separating procedure
previously performed.
300-C32X
