13 SIGMANET
13.2 Operation
13.2.1 Operating panels
The following operating panels can be connected in SIGMASYS systems:
SIGMANET
operating panel
GMA
operating panel
SIGMASYS C
operating panel
S24230-F130-A4 S24236-F4-A1 S24230-F515-A2
Connection to:
SIGMANET
V24 Spur OP
SIGMASYS C
Installation in
SIGMASYS M
SIGMASYS C
SIGMASYS L
OP sloting panel
cabinet
OP housing
Table 38: Operating panels
Possible operation is gray marked in the fields.
One or more responsibilities can be parameterised centrally for every operating panel. This
means, for example, that before it outputs an alarm signal output the SIGMASYS software
checks which operating panel (or GMA Manager) has given the alarm. The responsibilities
cannot be modified by the customer during live operation. If the operating panel is responsible
for multiple (or all) control and indicating panels in a SIGMANET system, the operating pa-
nel’s LED displays operate as general indications. To obtain clear and detailed information on
the display, press the “Display” button.
In addition control and indicating panel responsibility, alarm types/criteria can also be param-
eterised to differentiate between:
• Alarms (including prealarm, prewarning)
• Faults
• Signals (including armed/unarmed)
• Inspections
The alarm types selected are displayed as activated on the relevant operating panel. The
other alarm types are entered as “silent”, i.e. without internal acoustic alarm (modification
possible).
An EN 54-4-compliant power supply and 12 Ah batteries (minimum) are to be provided to
supply power to the remote operating panel. Both the PSU and the batteries should be in-
stalled in a SIGMASYS empty housing (S24230-C512-A1) adjacent to the operating panel.
13.2.2 SIGMANET operating panel S24230-F130-A4
The operating panel will be supplied by a membrane keyboard as of Version 2.6.
New features:
• 6 freely programmable function keys
• 2 additional cursor keys
