Siemens SIGMASYS M User Manual

4 Project planning for control and indicating panels
Warning: SIGMANET P is not compatible with the standard SIGMANET.
SIGM ch ANET P control and indicating panels are networked using 2-pole copper wire whi
can be up to 1000 meters long. A SAFEDLINK repeater can be used to increase the range.
4.4.5 SIGMANET P coupler (from mid-2006)
SIGMASYS C control and indicating panels and SIGMANET operating panels can be con-
indicating panels S24230-B72-A1
)
operating panels S24230-B71-A1
el
empty housing S24230-B73-A1
c lers include all the modules and mechanical parts required for connection or installa-
nected either to SIGMASYS M control and indicating panels with SOC P as a spur or to
SIGMANET P using a SIGMANET P coupler.
SIGMANET P couplers exist for:
• SIGMASYS C control and
for attaching to a SIGMASYS C operating panel (S24230-F515-A2
• SIGMANET
for attaching to the operating pan (S24230-F130-A4)
• SIGMASYS
The oup
tion, including the SIGMASYS SOC P module, FN2001-D1 networking module, SIGMASYS
APL 20 P.
Multifunctional Danger Control and Indicating Panels SIGMASYS C and M (M-Modules) 21 / 128
Best.Nr. A24205-A337-B970 – Edition 12 (03/07)
