4 Project planning for control and indicating panels
A 38-character text can be entered for every object, every area, every detector zone, every
output of the type AT/ST/EV/AL and every detector.
The detector group text is displayed if no detector text is entered.
The detector group text should preferably be programmed in order to save data points.
Additional requirements for number assignment must be observed in the case of D100 con-
nection
see section “D100 Interfaces (Version 3.0 and later)” on page 28>.
4.1.2 Programming limitations at control and indicating panels
A maximum of 8 objects can be programmed for each control and indicating panel (255 ob-
jects per system).
Objects cannot be centrally programmed for multiple control and indicating panels.
The object numbers must not contain leading zeros.
Up to 89 areas can be programmed per object (up to Version 2.5: only 32 areas).
200 detector zones can be programmed per area.
With control and indicating panels with a software version lower than V3.1, a maximum of 256
outputs per MPC module
or SIGMASYS C control and indicating panel can be configured.
20 commands per operating input are possible (maximum 200 commands distributed over
100 inputs).
With regard to operating panel function keys, a maximum of 20 commands can be assigned
to one key.
A maximum of 60 commands can be configured per operating panel.
The number of individually identifiable event locations, detector zones and zones must not
exceed 1750 per SIGMASYS control and indicating panel.
A maximum of 2500 datapoints can be programmed per SIGMASYS control and indicating
panel. This includes the sum of individually identifiable event locations, detector zones, areas,
outputs and non-coded text.
SIGMASYS control and indicating panel
limitations
Includes total of:
2500 datapoints
Event locations, detector zones, zones, outputs and non-coded
text
Subset limitations
1750 Event locations, detector zones, zones
1700 Individually identifiable detectors
1512 Detector zones
1512 Non-coded text (38 characters)
1512 Outputs (can be activated system-wide)
Table 3: Control and indicating panel limitations
Multifunctional Danger Control and Indicating Panels SIGMASYS C and M (M-Modules) 11 / 128
Best.Nr. A24205-A337-B970 – Edition 12 (03/07)
