Siemens SIGMASYS M - Parameter Sets for Linear Smoke Detector FDL241-9; Table32: Parameter Sets for FDOOT, FDO and FDT Detectors; Table33: Parameter Sets for Flame Detectors FDF221 and FDF241; Table34: Parameter Sets for Linear Smoke Detector FDL241-9

12 Monitored lines
DOOT: suppression X
DO: universal X X
DO: robust X X X Standard
DO: sensitive X X X Standard plus
DT: 60°C ROR (A1R) X X X
DT: 80°C ROR (BR) X X X
DT: 60°C stat. (A1S) X X
DT: 80°C stat. (B1S) X X
Customized/
Download 1
X X X
Customized/
Download 2
X X X
Table32: Parameter sets for FDOOT, FDO and FDT detectors
= Default setting
ROR = Rise Of Rate Differential detector
Parameter sets for flame detectors FDF221 and FDF241
Parameter sets FDF221-9 FDF241-9
robust X w/out SR X with SR
universal X with SR
universal fast X w/out SR X with SR
sensitive X w/out SR X with SR
sensitive fast X w/out SR X with SR
rapid X w/out SR
Motor test bed X w/out SR
Customized/
Download 1
X
Customized/
Download 2
X
Table33: Parameter sets for flame detectors FDF221 and FDF241
= Default setting
SR = Sun resistance
12.6.4 Parameter sets for linear smoke detector FDL241-9
standard UB=fault
standard UB=Alarm
sensitive UB=fault
sensitive UB=Alarm
very sens. UB=fault
very sens. UB=Alarm
Customized / Download
1
Customized / Download
2
Table34: Parameter sets for linear smoke detector FDL241-9
UB = Interruption of light beam
88 / 128 BMT Project Planning Guidelines
Best.Nr. A24205-A337-B970 – Edition 12 (03/07)
