Supplements to ET 200SP documentation
2.4 I/O module manuals
Product information on the documentation of the ET 200SP distributed I/O system
Product Information, 09/2019, A5E03799595-BD
43
In the manual for Energy Meter 480VAC ST, Edition 12/2015
In the device manual for Energy Meter 480VAC ST, the measured value ID and the
associated measured variables for the complete performance are reversed. The correct
association is shown in the table below:
Measured value
ID
Measured variables
Unit
34
Total active power L1L2L3
W
35
Total reactive power L1L2L3
var
36
Total apparent power L1L2L3
VA
65 Max. total active power W
66
Max. total reactive power
var
67 Max. total apparent power VA
95
Min. total active power
W
96
Min. total reactive power
var
97
Min. total apparent power
VA
If you use the user-data mapping via data record DS 130, note that the texts for the
measured variables are also displayed incorrectly during configuration.
During configuration of the measured variables for the total active, reactive, and apparent
power, select the following texts:
Desired measured variable for the user-data
mapping
Text to select during configuration
Total active power L1L2L3
Total apparent power L1L2L3 (ID00034)
Total reactive power L1L2L3
Total active power L1L2L3 (ID00035)
Total apparent power L1L2L3
Total reactive power L1L2L3 (ID00036)
Max. total active power
Max. total apparent power (ID00065)
Max. total reactive power
Max. total active power (ID00066)
Max. total apparent power
Max. total reactive power (ID00067)
Min. total active power
Min. total apparent power (ID00095)
Min. total reactive power
Min. total active power (ID00096)
Min. total apparent power
Min. total reactive power (ID00097)
The project configuration modification described above is no longer required if the following
tools and GSD files are used:
● STEP 7 (TIA Portal) as of V14
● STEP 7 (TIA Portal) as of V5.5 SP4 with HSP 0227
● GSD file GSDML-V2.32-ET200SP-20160706
