Module overview of ET 200SP
1.2 CPUs
Product information on the documentation of the ET 200SP distributed I/O system
14 Product Information, 09/2019, A5E03799595-BD
1.2 CPUs
CPUs
CPU
Number in pack
Article number
CPU 1510SP-1 PN with server module
Pack of 1
6ES7510-1DJ0x-0AB0
CPU 1510SP F-1 PN with server module
Pack of 1
6ES7510-1SJ0x-0AB0
CPU 1512SP-1 PN with server module
Pack of 1
6ES7512-1DK0x-0AB0
CPU 1512SP F-1 PN with server module Pack of 1 6ES7512-1SK0x-0AB0
CPU 1515SP PC with server module
Pack of 1
6ES7677-2AAxx-0xx0
Important differences between CPUs...PN
Features
CPU 1510SP-1
PN
CPU 1510SP F-1
PN
CPU 1512SP-1 PN
CPU 1512SP F-1 PN
Bus connection PROFINET:
BusAdapter (port 1, 2)
• BA 2xRJ45 (as of firmware version
1.6)
• BA 2xFC (as of firmware version
V1.6)
RJ45, integrated (port 3)
PROFINET:
BusAdapter (port 1, 2)
• BA 2xRJ45 (as of firmware version 1.6)
• BA 2xFC (as of firmware version V1.6)
• BA 2xSCRJ (as of firmware V1.8)
1
• BA SCRJ/RJ45 (as of firmware V1.8)
1
• BA SCRJ/FC (as of firmware V1.8)
1
• BA 2xLC (as of firmware V2.0)
1
• BA LC/RJ45 (as of firmware V2.0)
1
• BA LC/FC (as of firmware V2.0)
1
RJ45, integrated (port 3)
PROFIBUS:
PROFIBUS DP connection socket via CM DP communication module
Number of modules
64
Data work memory
750 KB
750 KB
1 MB
1 MB
Code work memory
100 KB
150 KB
200 KB
300 KB
Address space
1280 bytes/2560 bytes
2
Multi hot-swapping
Yes
Can be used for safety
applications (supports
PROFIsafe V2.0)
No Yes No Yes
1
Only with article numbers 6ES7512-1DK01-0AB0 and 6ES7512-1SK01-0AB0
2
Only 6ES7510-1DJ01-0AB0, 6ES7512-1SJ01-0AB0, 6ES7512-1DK01-0AB0 and 6ES7512-1SK01-0AB0 with FW
version V2.0
