Module overview of ET 200SP
1.3 Interface modules
Product information on the documentation of the ET 200SP distributed I/O system
16 Product Information, 09/2019, A5E03799595-BD
1.3 Interface modules
Interface modules
Interface modules
Number in pack
Article number
Interface module IM 155-6 PN BA
Pack of 1
6ES7155-6AR00-0AN0
Interface module IM 155-6 PN ST
• with BusAdapter BA 2xRJ45 and server module
Pack of 1 6ES7155-6AA01-0BN0
• with server module
Pack of 1 6ES7155-6AU01-0BN0
Interface module IM 155-6 PN/2 HF with server module
Pack of 1
6ES7155-6AU01-0CN0
Interface module IM 155-6 PN/3 HF with server module
Pack of 1
6ES7155-6AU30-0CN0
Interface module IM 155-6 PN HS with server module
Pack of 1
6ES7155-6AU00-0DN0
Interface module IM 155-6 DP HF with PROFIBUS FastConnect bus con-
nector (6ES7972-0BB70-0XA0) and server module
Pack of 1 6ES7155-6BA01-0CN0
Important differences between the interface modules
Features
IM 155-6 PN BA
IM 155-6 PN ST
IM 155-6 PN/2 HF
IM 155-6 PN/3 HF
IM 155-6 PN HS
IM 155-6 DP HF
Bus con-
nection
PROFINET:
2xRJ45, inte-
grated
PROFINET:
BusAdapter
• BA 2xRJ45 (as
of firmware
V1.0)
• BA 2xFC (as of
firmware V1.0)
PROFINET:
BusAdapter
• BA 2xRJ45 (as of
firmware V2.0)
• BA 2xFC (as of
firmware V2.0)
• BA 2xSCRJ (as of
firmware V2.2)
• BA SCRJ/RJ45 (as
of firmware V3.1)
• BA SCRJ/FC (as of
firmware V3.1)
• BA 2xLC (as of
firmware V3.3)
• BA LC/RJ45 (as of
firmware V3.3)
• BA LC/FC (as of
firmware V3.3)
PROFINET:
BusAdapter
• BA 2xRJ45 (as of
firmware V4.0)
• BA 2xFC (as of
firmware V4.0)
• BA 2xSCRJ (as of
firmware V4.0)
• BA SCRJ/RJ45 (as
of firmware V4.0)
•
BA SCRJ/FC (as of
firmware V4.0)
• BA 2xLC (as of
firmware V4.0)
• BA LC/RJ45 (as of
firmware V4.0)
• BA LC/FC (as of
firmware V4.0)
PROFIBUS:
PROFIBUS DP
connection socket
Number of
modules
12 32 64 30 32
RESET
button
No Yes IM 155-6 PN/2 HF: Yes
IM 155-6 PN/3 HF: No
Yes Not necessary
