Supplements to ET 200SP documentation
2.4 I/O module manuals
Product information on the documentation of the ET 200SP distributed I/O system
42 Product Information, 09/2019, A5E03799595-BD
2.4.2 Analog module device manuals
Manuals for analog input modules
AI 4xI 2-wire 4..20mA HART 11/2014
Section 5.2 Parameters
that the settings in the "Interference frequency suppression" parameter have a direct
effect on the cycle time of the module. The analog value is therefore also affected by
additionally set filtering via the "Smoothing" parameter.
Manuals AI 2xU/I 2-/4-wire HF, Edition 12/2015; AI Energy Meter 480VAC ST, Edition 12/2015
For configuration with STEP 7 V13 or higher (TIA Portal), real values between -7x10
28
and
+7x10
28
can be input. This is true for configuration via HSP and via GSD file (PROFINET).
For configuration with STEP 7 V5.5 SP4 as of HF7, configuration by means of GSD file
(PROFINET) with REAL values of -1.175x10
38
to +3.402x10
38
is possible.
With STEP 7 SP4 to HF6, parameter assignment of REAL values is not possible. Functions
that require REAL values are not available in this case.
Manuals AI Energy Meter 400VAC ST, Edition 12/2015; AI Energy Meter 480VAC ST, Edition
12/2015
Requirements for the operation of the AI Energy Meter on slot 1 of the ET 200SP:
AI Energy Meter 400VAC ST
(6ES7134-6PA01-0BD0)
AI Energy Meter 480VAC ST
(6ES7134-6PA20-0BD0)
IM 155-6 PN BA (6ES7155-6AR00-0AN0)
Can be operated on slot 1 for all IM 155-6 PN BA
IM 155-6 PN ST (6ES7155-6AU00-0BN0) Can be operated on slot 1 for IM 155-6 PN ST from firmware version V3.1
and higher and functional status FS 07
IM 155-6 PN HF (6ES7155-6AU00-0CN0) Can be operated on slot 1 for IM 155-6 PN HF from firmware version
V3.0 and higher and functional status FS 05
IM 155-6 DP HF (6ES7 155-6BU00-0CN0) Can be operated on slot 1 for IM 155-6 DP HF from firmware version
CPU 1510SP-1 PN, CPU 1512SP-1 PN,
Can be operated on slot 1 for all CPUs
