Siemens SIMATIC AFD4 - Technical Specifications for Active Field Distributor AFD4 (FM) (6 ES7655-5 DX40-1 AA1)

Technical specifications
3.4 Technical specifications for active field distributor AFD4 (FM) (6ES7655-5DX40-1AA1)
Active field distributors AFD4, AFD4 (FM), AFD8 and AFS
36 Product Information, 02/2015, A5E03775304-AC
3.4
Technical specifications for active field distributor AFD4 (FM)
(6ES7655-5DX40-1AA1)
Technical specifications
Order No.
6ES7655-5DX40-1AA1
Product version
01
Dimensions and weight
Dimension W x H x D (mm) 220 x 120 x 83; without cable gland
Mounting dimensions (mm)
204 x 82
Weight
2000 g
Supply voltages
Description
Via bus; no auxiliary power necessary
Rated value
• Valid range, lower limit (DC)
16 V
• Valid range, upper limit (DC)
32 V
• Polarity reversal protection
Yes; in conjunction with FDC 157
• Overvoltage protection
No
Current consumption
• Current consumption at idle
24 mA
• Current consumption
24 mA + total current of all field devices
• Additional current consumption of AFD4 at
end of line
30 mA
• Current consumption at max. current output
per spur line
264 mA
Power loss
• Power loss, min.
384 mW
• Power loss, max.
3.2 W
Interfaces
PROFIBUS PA
Yes
FOUNDATION Fieldbus H1
Yes
Connections
Main lines
Quantity
2
Terminals (internal)
Screw-type terminals (2-pin)
Cable gland (enclosure)
M20
Cable type
Type A
• Min. cable diameter
Corresponds to cable gland used
• Max. cable diameter
• Min. conductor cross-section
0.2 mm
2
