Introduction
1.2 Active field distributor AFD4, AFD4 (FM) and AFD8
Active field distributors AFD4, AFD4 (FM), AFD8 and AFS
6 Product Information, 02/2015, A5E03775304-AC
also be considered. You can find more information about industrial security on the Internet
(http://www.siemens.com/industrialsecurity).
To stay informed about product updates as they occur, sign up for a product-specific
newsletter. You can find more information on the Internet
(http://support.automation.siemens.com).
Active field distributor AFD4, AFD4 (FM) and AFD8
Active field distributor AFD4 / AFD4 (FM) / AFD8
Field devices such as measuring instruments, sensors and actuators can be connected to
the active field distributors AFD4 / AFD4 (FM) / AFD8.
In conjunction with 2 FDC 157 couplers, the field distributors AFD4 / AFD4 (FM) / AFD8
enable operation of a
. You can use the following field distributors in a
segment:
● Up to 8 field distributors when using AFD4 / AFD4 (FM) / AFD8 only
● Up to 5 field distributors with mixed use of at least one AFDiS and other AFD4 / AFD4
(FM) / AFD8 field distributors
The total number of field devices in a segment is 31 devices and it is limited by a maximum
of 60 mA per spur line.
● Connection of field devices for a field bus in line or ring topology
● Automatic bus termination
● Automatic isolation of faulty segments
● Automatic connection of isolated segments after fault rectification
● Extending a segment during operation
● Short-circuit-proof spur lines
● AFD4: 2 M16 cable glands for the main line
● AFD8: 2 M16 cable glands for the main line
● AFD4 (FM): 2 M20 blanking caps for the main line
● AFD4: 4 M16 cable glands for up to 4 field devices
● AFD8: 8 M16 cable glands for up to 8 field devices
● AFD4 (FM): 4 M16 blanking caps for up to 4 field devices
● Connection using screw-type terminals
● Reverse polarity protection connections
