Technical specifications
3.5 Technical specifications of active field distributors AFD8 (6ES7157-0AG82-0XA0)
Active field distributors AFD4, AFD4 (FM), AFD8 and AFS
38 Product Information, 02/2015, A5E03775304-AC
Relative humidity
Operation, max.
95%
Degree of protection
IP66
Yes
Installation
Class I Zone 2 / Division 2
Yes
Class II, III Division 2
Yes
3.5
Technical specifications of active field distributors AFD8
(6ES7157-0AG82-0XA0)
Technical specifications
Order number
6ES7157-0AG82-0XA0
Product version
01
Dimensions and weight
Dimension W x H x D (mm)
360 x 120 x 83; without cable gland
Mounting dimensions (mm)
344 x 82
Weight
3000 g
Supply voltages
Description
By bus; no auxiliary power necessary
Rated value
• Low limit of permitted range (DC)
16 V
• High limit of permitted range (DC)
32 V
• Polarity reversal protection
Yes; in conjunction with FDC 157
• Overvoltage protection
No
Power consumption
• Power consumption at no-load
34 mA
• Power consumption
34 mA + total current of all field devices
• Additional power consumption of the AFD8 at
end of line
30 mA
• Power consumption at max. current output
per spur line
514 mA
Power loss
• Power loss, min.
544 mW
• Power loss, max.
4.1 W
Interfaces
PROFIBUS PA
Yes
FOUNDATION Fieldbus H1
Yes
