Technical specifications
3.7 Abbreviations
Active field distributors AFD4, AFD4 (FM), AFD8 and AFS
42 Product Information, 02/2015, A5E03775304-AC
Between main line and spur lines
Passive, no repeater function
Between main line and spur lines
Environmental requirements
• Min.
-40 °C
• Max.
70 °C
Storage/transport temperatures
• Min.
-40 °C
• Max.
85 °C
Class I Zone 2 / Division 2
Spur; Connection for field devices (spur line)
T Trunk, connection of the main line between the field distributors AFD4 / AFD4
(FM) / AFD8, AFS or FDC
