Technical specifications
3.6 Technical specification of active field distributors AFS (6ES7157-0AG80-0XA0)
Active field distributors AFD4, AFD4 (FM), AFD8 and AFS
40 Product Information, 02/2015, A5E03775304-AC
Galvanic isolation
Between main line and spur lines
No
Environmental requirements
Operating temperature
• Min.
-40 °C
• Max.
70 °C
Storage/transport temperatures
• Min.
-40 °C
• Max.
85 °C
Relative humidity
Operation, max.
95%
Degree of protection
IP66
Yes
Installation
Zone 2 / Zone 22
Yes
Class I Zone 2 / Division 2
Yes
3.6
Technical specification of active field distributors AFS
(6ES7157-0AG80-0XA0)
Technical specifications
Order number
6ES7157-0AG80-0XA0
Product version
01
Dimensions and weight
Dimension W x H x D (mm)
220 x 120 x 83; without cable gland
Mounting dimensions (mm)
204 x 82
Weight
2000 g
Supply voltages
Description
By bus; no auxiliary power necessary
Rated value
• Low limit of permitted range (DC)
16 V
• High limit of permitted range (DC)
32 V
• Polarity reversal protection
Yes; in conjunction with FDC 157
• Overvoltage protection
No
Power consumption
• Power consumption at no-load
54 mA
Power loss
• Power loss, min.
864 mW
