Installing and Wiring the C7-635
3-2
C7-635 Control System
A5E00155581-04
The strip is inserted as follows:
Step Action
1. Place the device with the front plate facing downward.
2. Remove any labeling strips that have been previously inserted.
3. With the labeling pointing downward, insert the new labeled strips into the slits
on the front panel (use tweezers, if necessary). The position of the eight labeling
strips is marked in Figure 3-1 with arrows.
Labeling strips
Figure 3-1 Inserting labeling strips for C7-635 Key
