A-1
C7-635 Control System
A5E00155581-04
Technical Specifications
A.1 Technical Specifications for Complete Apparatus
In this table, you will find the technical specifications for the complete apparatus.
Table A-1 Technical Specifications for C7-635
General Specifications
C7-635 Touch C7-635 Key
Order No. 6ES7635-2EB01-0AE3 6ES7635-2EC01-0AE3
Dimensions
Mounting dimensions
260 x 199 x 79 mm (WxHxD)
231 x 183 mm
(tolerance: +1 mm)
260 x 274 x 80 mm (WxHxD)
231 x 257 mm
(tolerance: +1 mm)
Mounting depth for 2-module I/O
set:
144 mm (measured from the outer metal edge of the cutout)
Mounting depth for 4-module I/O
set:
195 mm (measured from the outer metal edge of the cutout)
Weight 1,380 g 1,500 g
Display
Active screen surface
Resolution
Colors
116 x 87 mm
320 x 240
Blue mode in 4 shades
Keyboard Resistive touch
Two-key membrane keyboard
Matrix keyboard
61-key membrane keyboard
Power Supply C7-635 Touch C7-635 Key
Supply voltage (U
N
)
• Polarized input voltage
• Voltage interruption
(can be jumpered)
24 VDC; (20.4 VDC to 28.8 VDC, Safety Extra Low Voltage, SELV)
The C7-635 has no integrated protection against high-energy
interfering pulses in the μs-range (surge pulse). Consult the S7-300,
CPU 31xC and CPU 31x: Hardware and Installation manual for the
required protective specifications.
Yes
≥ 20 ms
Current consumption Typically 350 mA in no-load
operation
1 A maximum
Typically 350 mA in no-load
operation
1 A maximum
Inrush current 2 A for 70 ms 2 A for 70 ms
Power losses 14 W 14 W
Ungrounded configuration Not possible
Software C7-635 Touch C7-635 Key
TP/OP operating system platform MS Windows CE MS Windows CE
A
