C7-635 Control System
A5E00155581-04
Preface
Purpose of this Manual
This manual provides a complete overview of the C7-635 Control System and
assistance with its installation and commissioning. Options for connecting
additional devices are explained, and the required components are presented.
Scope of Manual
This manual is applicable to the following:
C7 Order Number As of Version
Firmware/Hardware
C7-635 Touch 6ES7 635-2EB01-0AE3 CPU V2.0.7 / 01
HMI V 6.0.2.23 (Win CE)
C7-635 Key 6ES7 635-2EC01-0AE3 CPU V2.0.7 / 01
HMI V 6.0.2.23 (Win CE)
Audience and Knowledge Requirements
This manual is intended for persons having the required qualifications to
commission, operate, and program the hardware product described.
You should be familiar with the use of computers or similar tools (such as
programming devices) under the Windows 98/2000/NT 4.0/XP operating system
and be knowledgeable regarding the basic STEP 7 software and ProTool
configuration software and their documentation.
C7-635 Documentation Package
The C7-635 consists of the following individual components:
• SIMATIC S7-CPU 314C-2 DP
• SIMATIC Touch Panel TP170 B (C7-635 Touch) and Operator Panel OP170 B
(C7-635 Key)
Manuals providing detailed information on these individual components are
included in this documentation package. These manuals are essential when
working with the C7-635.
