Technical Specifications
A-13
C7-635 Control System
A5E00155581-04
Integrated I/O
• Default addresses of the integrated
Digital inputs 124.0 to 126.7
Digital outputs 124.0 to 125.7
Analog inputs 752 to 761
Analog outputs 752 to 755
Integrated Functions (see the CPU 31xC Technological Functions manual)
Counters,
Frequency meters,
Pulse outputs (pulse width
modulation)
4 channels in total,
Frequency meter up to 60 kHz, maximum,
Pulse outputs up to 2.5 kHz, maximum
Controlled positioning 1 channel
Integrated SFB ”controlling” PID controller
