C-1
Operator Panel OP3
Edition 11/99
Technical Data
Housing
Front panel B × H × D (mm) 148 × 76 × 27
Mounting cutout B × H (mm) 138 × 68 (DIN 43700)
Useful depth approx. (mm) 25
Protection type
front
rear
IP65
IP20
Weight approx. (kg) 0,22
Processor
Type 80C32 (Intel)
Clock frequency 10.5 MHz
Memory
Flash memory for configuration data 128 KB
SRAM working memory 128 KB
EPROM firmware 512 KB
Display
Type
STN display with LED
background illumination
Number of lines 2
Characters per line 20
Character height (mm) 5
Keyboard
Type Membrane keyboard
Number of system keys 18
C
