Commissioning the device
4.3 Parameter assignment for Comfort Panel
Comfort Panels
108 Operating Instructions, 07/2017, A5E36770603-AB
Assigning sounds and events
1. Change to the "Sound" tab.
2. Under "Event", select the event to which you want to assign a sound.
Events to which a sound is already assigned are marked with a loudspeaker symbol.
3. Select the desired sound for the event under "Sound":
– Select either a standard sound or use "Browse" to select a "*.WAV" file from the file
system.
– Test the sound with "Play", if required.
– Stop the output with "Stop", if required.
4. Confirm your entries with "OK".
Sounds and properties of acoustic signals are set.

Siemens SIMATIC HMI TP1500 Comfort Specifications

General

Flash Memory	12 MB
Supply Voltage	24 V DC
Brightness	400 cd/m²
Flash Memory Size	12 MB
Display Size	15 inches
Touch Technology	Resistive
Interfaces	Ethernet, USB
Protection Rating	IP65
Display Type	TFT
Touchscreen Type	Analog-resistive
Communication Ports	Ethernet, USB
Protection Class	IP65
