Siemens SIMATIC HMI TP1500 Comfort User Manual

Commissioning the device
4.2 Operating the device
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
69
4.2
Operating the device
4.2.1
Reference for system keys
You operate key HMI devices using the system keys.
Alphanumeric assignment of system keys
The following table shows the alphanumeric assignment of the system keys from "0" to "9":
Key
Alphanumeric assignment
1
<space>\@#%?!"':;<>()[]{}€$&%^°~|_1
2
ABCÄÀ2
3
DEFÈÉ3
4 GHI4
5
JKL5
6 MNOÖ6
7
PRQRSß7
8
TUVÜ8
9
WXYZ9
0
+-*/=0
The characters available for input depend on the entry field involved, e.g. the entry of an
alphanumeric value using the system keys.
Key 1 <space> can be used instead of the <ENTER> key in the current project
General functions
You initiate functions on HMI devices with keys by using a key or keyboard shortcuts. With
keyboard shortcuts, hold the first key down. Then press the second button.

Siemens SIMATIC HMI TP1500 Comfort Specifications

General

Flash Memory	12 MB
Supply Voltage	24 V DC
Brightness	400 cd/m²
Flash Memory Size	12 MB
Display Size	15 inches
Touch Technology	Resistive
Interfaces	Ethernet, USB
Protection Rating	IP65
Display Type	TFT
Touchscreen Type	Analog-resistive
Communication Ports	Ethernet, USB
Protection Class	IP65
