Mounting and connecting the HMI device
3.2 Mounting the device
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
45
Proceed as follows:
1. Insert the HMI device into the mounting cutout from the front. The figure shows a
KP700 Comfort as an example.
2. Insert the mounting clip into the cutout provided on the HMI device.
3. Tighten the grub screw to secure the mounting clip.
Note
Adhere to the permitted torque when tightening the grub screws of the mounting clips:
• 4" model: 0.2 Nm
• 7" to 22" models: 0.5 Nm
4. Repeat steps 2 and 3 for all mounting clips.
5. Check the fit of the mounting seal.
Result
The HMI device is mounted and the relevant degree of protection is ensured at the front.
See also
Accessories (Page 22)

Siemens SIMATIC HMI TP1500 Comfort Specifications

General

Flash Memory	12 MB
Supply Voltage	24 V DC
Brightness	400 cd/m²
Flash Memory Size	12 MB
Display Size	15 inches
Touch Technology	Resistive
Interfaces	Ethernet, USB
Protection Rating	IP65
Display Type	TFT
Touchscreen Type	Analog-resistive
Communication Ports	Ethernet, USB
Protection Class	IP65
