Commissioning the device
4.2 Operating the device
Comfort Panels
Operating Instructions, 07/2017, A5E36770603-AB
71
Using the operating systems and Explorer
The table below shows the system key functions when using the operating system and the
Explorer:
Key or keyboard
shortcut
Function
Enables the taskbar and opens the Start menu.
Displays the loader.
Opens the task manager.
Toggles between the desktop and Explorer.
Navigates to the directory above.
Selects the first entry.
Selects the last entry.
Opens the shortcut menu.
Displays the properties.

Siemens SIMATIC HMI TP1500 Comfort Specifications

General

Flash Memory	12 MB
Supply Voltage	24 V DC
Brightness	400 cd/m²
Flash Memory Size	12 MB
Display Size	15 inches
Touch Technology	Resistive
Interfaces	Ethernet, USB
Protection Rating	IP65
Display Type	TFT
Touchscreen Type	Analog-resistive
Communication Ports	Ethernet, USB
Protection Class	IP65
