Operating hardware
4.2 Web server
CP 1604 / CP 1616
54 Operating Instructions, 02/2017, C70000-G8976-C218-08
"IP address"
If a link is available here, this will bring you to the Web server of the selected, configured
device.
"Topology"
The "Module information" and "Topology" Web pages are linked. If you click on the selected
module in "Topology", you automatically jump to this module in the graphic view of the set
topology on the "Topology" Web page. The module appears in the visible area of the
"Topology" Web page and the device head of the selected module flashes for several
seconds.
"Filter"
You have the option of sorting the table according to certain criteria:
1. Select a parameter from the drop-down list.
2. If applicable, enter the value of the selected parameter.
3. Click on "Filter".
The filter conditions remain active even after updating a page.
To disable the filter settings, click "Filter" again.
"Status" tab
This tab contains information on the status of the selected module if there is a fault or a
message pending.
"Identification" Tab
This tab contains data to identify the selected module.
Note
In this tab, only data that was configured offline is displayed, but no online data of modules.
