Siemens SIMATIC NET RUGGEDCOM RS900 User Manual

Installing the Device
2.3.1Mounting the Device on a DIN Rail
1
2
3
2
1
1
1
DIN Rail
2
DIN Rail Adapter
Figure2.1 Mounting the Device to a DIN Rail
2. Insert a flathead screwdriver into the slot of the sliding release and move it
down.
3. Push the device against the bottom of the DIN rail, then let go of the sliding
release to latch the device.
Removing the Device
To remove the device from a DIN rail, do the following:
1. Insert a flathead screwdriver into the slot of the sliding release and move it
down.
10
RUGGEDCOM RS900
Equipment Manual, 11/2023, C79000-G8976-1024-16
