Technical Specifications
5.9Dimension Drawings
5.9 Dimension Drawings
Note
All dimensions are in millimeters, unless otherwise stated.
99.06
187.96
168.66
65.3
116.59
7.87
Figure5.1 Overall Dimensions
28
RUGGEDCOM RS900
Equipment Manual, 11/2023, C79000-G8976-1024-16
