Technical Specifications
5.7Operating Environment
Tx (dBm)
Mode
Connector
Type
Tx λ
(nm)
a
Cable
Type (μm)
Minimum Maximum
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(km)
a
Power
Budget
(dB)
50/125 -22.5 -14 -33.5 -14 2 11
MM MTRJ 1300
62.5/125 -19 -14 -33.5 -14 2 14.5
50/125 -22.5 -14 -33.9 -14 2 11.4
MM SC 1300
62.5/125 -19 -14 -33.9 -14 2 14.9
50/125 -22.5 -14 -33.9 -14 2 11.4
MM ST 1300
62.5/125 -19 -14 -33.9 -14 2 14.9
MM LC 1310 62.5/125 -19 -14 -32 -14 2 13
SM ST 1310 9/125 -15 -7 -34 -3 20 19
SM LC 1300 9/125 -15 -8 -38 -3 20 23
SM LC 1310 9/125 -5 0 -35 -3 50 30
SM LC 1310 9/125 0 5 -37 0 90 37
SM SC 1300 9/125 -15 -8 -31 -7 20 16
SM SC 1310 9/125 -5 0 -34 -3 50 29
SM SC 1310 9/125 5 0 -37 0 90 42
a
Typical.
5.7 Operating Environment
The RUGGEDCOM RS900 is rated to operate under the following environmental
conditions.
Ambient Operating
Temperature
a
-40 to 85 °C (-40 to 185 °F)
Ambient Storage Temperature -40 to 85 °C (-40 to 185 °F)
Ambient Relative Humidity
b
5% to 95%
Maximum Altitude 2000 m (6562 ft)
a
Measured from a 30 cm (12 in) radius surrounding the center of the enclosure.
b
Non-condensing.
5.8 Mechanical Specifications
Weight 1.2 kg (2.7 lbs)
Ingress Protection IP30
Enclosure 20 AWG Galvanized Steel
RUGGEDCOM RS900
Equipment Manual, 11/2023, C79000-G8976-1024-16
27
