Device Management
3
This section describes how to connect to and manage the device.
3.1 Connecting to the Device
The following describes the various methods for accessing the RUGGEDCOM RS900
console and Web interfaces on the device. For more detailed instructions, refer to the
"RUGGEDCOM ROS Configuration Manual" for the RUGGEDCOM RS900.
Console Port
Connect a workstation directly to the RS232 serial console port to access the boot-
time control and RUGGEDCOM ROS console interface. The console port provides
access to RUGGEDCOM RS900's console interface.
Note
The serial console port is intended to be used only as a temporary connection during
initial configuration or troubleshooting, and should only be used in a safe area (as
defined by IEC 60079-0, Edition 6.0).
Use the following settings to connect to the port:
Speed 57600 baud
Data Bits 8
Stop Bit 1
Parity None
Flow Control Off
Terminal ID VT100
RUGGEDCOM RS900
Equipment Manual, 11/2023, C79000-G8976-1024-16
19
