Technical Specifications
5.4Supported Networking Standards
5.4 Supported Networking Standards
The following networking standards are supported by RUGGEDCOM RS900:
Standard 10 Mbps
Ports
100 Mbps
Ports
1000 Mbps Ports Notes
IEEE 802.3x • • • Full Duplex Operation
IEEE 802.3z • 1000Base-LX
IEEE 802.3ab • 1000Base-Tx
IEEE 802.1D • • • MAC Bridges
IEEE 802.1Q • • • VLAN (Virtual LAN)
IEEE 802.1p • • • Priority Levels
5.5 Copper Ethernet Port Specifications
The following details the specifications for copper Ethernet ports that can be ordered
with the RUGGEDCOM RS900.
Speed
a
10/100Base-TX
Connector RJ45
Duplex
a
FDX/HDX
Cable Type
b
> CAT 5
Wiring Standard
c
TIA/EIA T568A/B
Maximum Distance
d
100 m (328 ft)
Isolation
e
2.5 kV
a
Auto-negotiating.
b
Shielded or unshielded.
c
Auto-crossover and auto-polarity.
d
Typical distance. Dependent on the number of connectors and splices.
e
RMS 1 minute.
5.6 Fiber Optic Ethernet Port Specifications
The following details the specifications for fiber Ethernet ports that can be ordered
with the RUGGEDCOM RS900.
Note
• All optical power numbers are listed as dBm averages. To convert from average
to peak, add 3 dBm. To convert from peak to average, subtract 3 dBm.
• Maximum segment length is greatly dependent on factors such as fiber quality,
and the number of patches and splices. Consult a Siemens sales associate when
determining maximum segment distances.
26
RUGGEDCOM RS900
Equipment Manual, 11/2023, C79000-G8976-1024-16
