Technical Specifications
5.9Dimension Drawings
13.64
101.6 11.2
78.74 120.65
194.06
83.20
183.90
130.2
Figure5.2 Panel and DIN Rail Mount Dimensions
RUGGEDCOM RS900
Equipment Manual, 11/2023, C79000-G8976-1024-16
29
