Application and functions
1.5 Compatibility with previous product
CP 443-5 Extended
Equipment Manual, 01/2023, C79000-G8976-C162-10
25
By using this function, the time required for loading firmware is reduced significantly
compared with the old function.
CPxxx (FWL) cannot be used
The setting CPxxx(FWL) in the interface parameter assignment cannot be used with this CP
type.
Download the firmware only via the PROFIBUS interface of the CP. To download the firmware,
you can use the following:
PROFIBUS connecting cable 6ES7 901-4BD00-0XA0
PROFIBUS cable with a maximum length of 200 m
The use of an MPI cable is not permitted!
Version history / predecessor products
The document “Version History for the SIMATIC NET S7 CPs" contains information on the all
the previously supplied PROFIBUS CPs for SIMATIC S7. An up-to-date version of this document
is available for downloading on the Internet under the following entry ID:
9836605 (https://support.industry.siemens.com/cs/ww/en/view/67225941)
1.5.2 Replacing older modules / module replacement
Module replacement
Please follow the procedure below when replacing an older module with the module
described in this document:
6GK7 443-5DX01-0XE0
6GK7 443-5DX02-0XE0
6GK7 443-5DX03-0XE0
6GK7 443-5DX04-0XE0
Configuration unchanged (replacing a defective module)
If you have no requirements beyond what you had with the previous CP, you do not
need to make changes in the configuration.
All you need to do is replace the hardware with the power supply turned off.
Extending the configuration (using new functions)
If you want to use options that you had not used with the previous CP, follow the steps
below (see also Chapter 3 (Page 29)):
1. In STEP 7, replace the already configured CP 443-5 with the new module; You will
find this in the hardware catalog.
2. Modify your configuration according to your requirements, for example in the
Properties dialog for the PROFIBUS subnet.
3. Save, compile and load the configuration data to the CPU or CP again.
