Siemens SIMATIC NET S7-400 Equipment Manual

Application and functions
1.3 Requirements for use
CP 443-5 Extended
14 Equipment Manual, 01/2023, C79000-G8976-C162-10
CPU Article number of
the CPU:
6ES7...
Firmware
version
Number of
AG_SEND or
AG_RECV calls at
same time
a = SYNC/FREEZE functionality
b = DP-V1 functionality
c = CiR / HCiR functionality
1)
d = enable / disable DP slaves
e = identify bus topology
..416-2FN05-0AB0
..416-2FP07-0AB0
As of V5.0
64 / 64
+
+
+
+
+
CPU 416-5H
PN/DP
..416-5HS06-0AB0 V6.0 64 / 64 + + + + +
CPU 417-4 ..417-4XL04-0AB0
..417-4XT05-0AB0
..417-4XT07-0AB0
V4.0
64 / 64
+
+
+
+
-
As of V4.1
64 / 64
+
+
+
+
+
CPU 417-4H ..417-4HL04-0AB0
V4.0
64 / 64
-
+
+
-
-
as of V4.0.5
64 / 64
-
+
+
-
+
CPU 417-5H
..417-5HN08-0AB0
V6.0
64 / 64
-
+
+
-
+
Legend:
+ => The characteristic is supported / the listed mode is possible
- => The characteristic is not supported / the listed mode is not possible
1)
All CPUs are capable of CiR (the H-CPUs HCiR).
1.3.2 Converting older systems
In conjunction with the CP 443-5 Extended V 7.0, the functionality supported by the
discontinued CPU types listed in Table 2-2 is as follows:
• No DPV1 functionality
• No CiR functionality (DP slave, configurable extension)
• No identification of the bus topology by the user program
• Max. number of external DP lines per station: 4
• Number of operable CPs: 8
• Multicomputing
Table 1- 2 Use with no longer available CPU types - part 1
CPU Article number Version Number of AG_SEND or
AG_RECV calls at same
time
SYNC / FREEZE
CPU 412
6ES7 412-1XF01-0AB0
2 or higher
12 / 12
-
6ES7 412-1XF02-0AB0
2 or higher
12 / 12
+
CPU 413
6ES7 413-1XG01-0AB0
2 or higher
12 / 12
-
6ES7 413-1XG02-0AB0
1 or higher
12 / 12
+
CPU 413-2
6ES7 413-2XG01-0AB0
2 or higher
12 / 12
-
6ES7 413-2XG02-0AB0
1 or higher
12 / 12
+
CPU 414-1
6ES7 414-1XG01-0AB0
2 or higher
12 / 12
-
