Installation
1. Prepare the drill holes for wall mounting. For the precise dimensions, refer to the section
"SCALANCE S615 (Page66)".
2. Secure the device to the wall with two screws. When mounting on a wall, use mounting
󹪝ttings suitable for the type of wall.
3. Connect the power supply, refer to the section "Power supply (Page49)".
4. Fit the connectors for the digital input and digital output, refer to the section "Digital input/
output (Page51)".
5. Connect the device to the local network, refer to the section "Ethernet port (Page53)".
6. Connect the terminal with as short a cable as possible ≤ 150 mm and a large cross-sectional
area of 1.5 mm² to the functional ground of the system, see section "Terminals (Page 23)“ and
section “Grounding (Page50)“.
Installation and removal
4.3Wall mounting
SCALANCE S615
Operating Instructions, 05/2023, C79000-G8976-C389-08 35
