Description of the device
4.8 C-PLUG/KEY-PLUG
SCALANCE XM-400
Operating Instructions, 09/2018, C79000-G8976-C306-08
39
Function of the C-PLUG/KEY-PLUG
Do not remove or insert a C-PLUG/KEY-PLUG during operation
A C-PLUG/KEY-PLUG may only be removed or inserted when the device is turned off.
Saving configuration data and enabling layer 3 functionality
A PLUG is an exchangeable storage medium for storing the configuration data of the device.
This allows fast and uncomplicated replacement of a device. The PLUG is taken from the
previous device and inserted in the new device. The first time it is started up, the
replacement device has the same configuration as the previous device except for the device-
specific MAC address set by the vendor.
A C-PLUG stores the current information about the configuration of a device.
In addition to the configuration, a KEY-PLUG also contains a license with which layer 3
functionality is enabled.
Note
The device can also be operated without a C
-PLUG/KEY-PLUG.
How it works
Operating mode
In terms of the C-PLUG / KEY-PLUG, there are three modes for the device:
● Without C-PLUG/KEY-PLUG
The device stores the configuration in internal memory.
This mode is active if no C-PLUG/KEY-PLUG is inserted.
● With unwritten C-PLUG/KEY-PLUG
If an unwritten C-PLUG/KEY-PLUG (factory status or deleted with Clean function) is
used, the local configuration already existing on the device is automatically stored on the
inserted C-PLUG/KEY-PLUG during startup.
This mode is active as soon as an unwritten C-PLUG/KEY-PLUG is inserted.
● With written C-PLUG/KEY-PLUG
A device with a written and accepted C-PLUG/KEY-PLUG ("ACCEPTED" status)
automatically uses its configuration data during startup.
Acceptance is only possible if the data was written by a compatible device type.
This mode is active as soon as a written C-PLUG/KEY-PLUG is inserted.
