Antennas

6.3 SIMATIC RF620A

SIMATIC RF600

System Manual, 06/2019, J31069-D0171-U001-A22-7618

261

Directional radiation pattern ETSI on metallic mounting surface (15 cm x 15 cm)

Pattern of the vertical plane of the antenna

Pattern of the horizontal plane of the antenna

Figure 6-17 Directional radiation pattern RF620A ETSI on metallic mounting surface
