6.3 SIMATIC RF620A

SIMATIC RF600

262 System Manual, 06/2019, J31069-D0171-U001-A22-7618

Directional radiation pattern ETSI on non-metallic mounting surface

Pattern of the vertical plane of the antenna

Pattern of the horizontal plane of the antenna

Figure 6-18 Directional radiation pattern RF620A ETSI on non-metallic mounting surface
