Siemens Simatic S7-1500 Operating Instructions

CPU 1505SP (F) Ready4Linux Version 2.7
28 Operating Instructions, 05/2019, A5E46864285-AA
Installing
4
4.1 Delivery forms of the CPU
The CPU is delivered in different variants with different article numbers.
The Ready4Linux CPU 1505SP is delivered as a bundle and contains the following articles:
● CPU 1515SP PC2
● CFast card with base image for Ready4Linux
● Restore USB flash drive with base image for Ready4Linux, Backup and Restore Tool
(Page 72) and Diagnostics Tool (Page 89)
4.2 System Requirements
In order to use the CPU, your system must meet the following requirements:
Category
Requirement
Operating system Linux Debian 9.3 kernel version ≥ 4.9
Operator interface
Color monitor, keyboard and mouse or other pointing device (optional).
Communication
interface
One or more communication interfaces for communication with STEP 7 or other
S7 applications or for communication with distributed I/O
Supported plat-
forms
CPU 1515SP PC2

Siemens Simatic S7-1500 Specifications

General

Protection Class	IP20
Programming Language	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Memory	Work memory and load memory (integrated or external memory card)
I/O Modules	Digital I/O, Analog I/O, Technology modules, Communication modules
Safety Integrated	Yes (with fail-safe CPUs and modules)
Redundancy	CPU redundancy possible with specific CPU types
Temperature Range	0°C to 60°C (horizontal installation)
Digital Inputs	Scalable through digital input modules
Digital Outputs	Scalable through digital output modules
Analog Inputs	Scalable through analog input modules
Analog Outputs	Scalable through analog output modules
Backplane	Integrated backplane for module connection
Real-time clock	Integrated real-time clock
CPU Type	Various models available (e.g., CPU 1511-1 PN, CPU 1513-1 PN, CPU 1515-2 PN, CPU 1517-3 PN, CPU 1518-4 PN/DP)
