Parameters/address space
4.2 Parameters
Analog Input Module AI 8xU/R/RTD/TC HF (6ES7531-7PF00-0AB0)
28 Manual, 09/2016, A5E36647959-AB
The following parameter settings for the channels are possible:
Table 4- 2 Configurable parameters and their defaults
Parameters
Range of values
Default set-
ting
Parameter
assignment
in RUN
Scope with configuration software,
e.g., STEP 7 (TIA Portal)
Integrated in
the hardware
catalog
STEP 7
(TIA Portal) as
of V12 or GSD
file PROFINET
IO
GSD file
PROFIBUS DP
Diagnostics
• Missing supply voltage L+
Yes/No No Yes Channel
1)
Module
2)
• Overflow
Yes/No No Yes Channel Module
2)
• Underflow
Yes/No No Yes Channel Module
2)
• Reference channel error
Yes/No No Yes Channel Module
2)
• Wire break
Yes/No No Yes Channel Module
2)
Measuring
• Measurement type
See section Measur-
ing types and ranges
(Page 24)
Thermal
resistor RTD
(4-wire con-
nection
Yes Channel Channel
• Measuring range
Pt100 stand-
ard
Yes Channel Channel
• Operating mode • Standard
• Fast
Standard Yes Channel ---
4)
• Temperature coefficient
Pt: 0.003851
Pt: 0.003902
Pt: 0.003910 GOST
Pt: 0.003916
Pt: 0.003920
Ni: 0.006170 GOST
Ni: 0.006180
Ni: 0.006720
Cu: 0.00426 GOST
Cu: 0.00427
Cu: 0.00428 GOST
LG-Ni: 0.005000
0.003851 Yes Channel Channel
• Temperature unit • Kelvin (K)
• Fahrenheit (°F)
• Celsius (°C)
°C Yes Channel Module
