Parameters/address space
4.2 Parameters
Analog Input Module AI 8xU/R/RTD/TC HF (6ES7531-7PF00-0AB0)
Manual, 09/2016, A5E36647959-AB
29
Parameters
Range of values
Default set-
ting
Parameter
assignment
in RUN
Scope with configuration software,
e.g., STEP 7 (TIA Portal)
Integrated in
the hardware
catalog
STEP 7
(TIA Portal) as
of V12 or GSD
file PROFINET
IO
GSD file
PROFIBUS DP
• Interference frequency
suppression
400 Hz
60 Hz
50 Hz
10 Hz
50 Hz Yes Channel Module
• Smoothing
None/low/medium/hig
h
None Yes Channel Channel
• Reference junction for TC • Fixed reference
temperature
• Dynamic reference
temperature
• Internal reference
junction
• Reference channel
of the module
3)
Internal refer-
ence junction
Yes Channel Module
4)
• Dynamic ref-
erence tem-
perature
• Internal refer-
ence junction
• Reference
channel of the
module
• Fixed reference tempera-
ture
Temperature 25 °C Yes Channel ---
4)
• Scalable measuring range • Disable
• Enable
Disable Yes Channel Channel
4)
• Measuring range resolu-
tion
• 2 decimal places
• 3 decimal places
2 decimal
places
Yes Channel Channel
4)
• Measuring range center
Value within the nomi-
nal range of the
measuring range
0 Yes Channel Channel
4)
