New functions Applications Customer benefits
Larger code and data memory Increasing the memory for more comprehens
ive user programs:
• CPU 1504D TF: Code memory increased
from 2 to 4 MB and data memory from 4 to
6 MB
• CPU 1507D TF: Code memory increased
from 6 to 15 MB and data memory from 20
to 40 MB
Extended areas of application
Increased configuration limits
for motion control technolo
gies:
Increased configuration limits for motion con
trol technologies for CPU 1504D TF:
• Motion control resources increased from
2,400 to 3,200
• Motion control resources increased from
120 to 160
• Typical number of positioning axes at 4ms
servo/IPO cycle and 35% CPU load through
motion control increased from 10 to 12
axes
Extended areas of application
Support for TIA Portal option
package Safe Kinematics with
CPU 1507D TF (retroactively
approved with Safe Kinematics
from V17 and CPU firmware
from V2.9 onwards)
Movements of predefined kinematics with up
to 12 interpolating axes in a multi-dimensional
space can be securely monitored
Monitoring whether kinematics zones exit
the active work zone or enter the protection
or signal zones:
• Safe velocity monitoring
• Safe zone monitoring
• Safe orientation monitoring
Support for the supplementary
software S7-1500T Motion
Control KinPlus
(only for CPU 1507D TF)
With S7-1500T Motion Control KinPlus, you can
control Kinematics with up to 6 interpolating
axes.
• New pre-defined kinematics:
– Cartesian portal 3D with 2 orientations
– Delta picker 3D with 2 orientations
– 6-axis articulated arm with central hand
• User-defined kinematics 3D with 3 orienta
tions
Extended areas of application through kin
ematics types with more than four kinemat
ics axes
Extended version displays Extended version display in the TIA Portal, Web
server und diagnostic buffer export (for
example, SINAMICS Integrated version)
The firmware version of the SINAMICS Integ
rated can also be determined without SIN
AMICS Startdrive.
Thus, the SINAMICS Integrated version can
also be determined if it is not possible to go
online with SINAMICS Startdrive, for example
because the configured firmware version is
different from the firmware version of the
device
1
.
X142 technology I/Os,
event/cycle duration measure
ment
Apart from the measurement method "Single
period", there is also an additional measure
ment method "Multiple periods" available.
The period duration is determined based on all
periods in a measuring cycle, with the measur
ing cycle length corresponding to one applica
tion cycle (e.g. servo clock).
This method provides a more accurate meas
urement for short periods. In addition, meas
urement value variations are evened out.
15
Product overview
3.1 New functions
SIMATIC Drive Controller
Equipment Manual, 11/2022, A5E46600370-AC
