3.4 Hardware properties
Article numbers
SIMATIC Drive Controller with CPU 1504D TF: 6ES7615-4DF10-0AB0
SIMATIC Drive Controller with CPU 1507D TF: 6ES7615-7DF10-0AB0
Front and side views
The figure below shows the front view and side view of a SIMATIC Drive Controller.
① Holding clamp of shield support
② Top cover
③ Side nameplate
④ Spacer
⑤ Bottom cover
Figure 3-2SIMATIC Drive Controller front view and side view
23
Product overview
3.4 Hardware properties
SIMATIC Drive Controller
Equipment Manual, 11/2022, A5E46600370-AC
