Supported SINAMICS functions requiring a license
SINAMICS Integrated only supports the following licensed functions and Technology
Extensions (TEC) of a SINAMICS S120 CU320-2:
•
Safety Integrated Extended Functions
•
Safety Integrated Advanced Functions
•
Detent torque compensation
•
Advanced Position Control (APC)
•
Technology Extension VIBX (Vibration Extinction)
•
Technology Extension SERVCOUP (Servo Coupling)
•
Technology Extension DCDCCONV (DC-DC converter)
•
Technology Extension RAILCTRL (Rail Control, under development)
•
DCB Extension Library
•
Advanced Synchronous Reluctance Control
•
Controller Parameter Adaption
•
Dynamic network support
•
Line droop control
PROFIdrive Integrated
Cyclic communication between CPU and SINAMICS Integrated is based on PROFIdrive
mechanisms.
The communications services used for this are based on PROFIBUSDP and are processed over
an internal, high-performance interface.
Unsupported functions and components
SINAMICS Integrated provides a functional subset of the SINAMICS S120 CU320-2 drive
functions. The following functions/components are not supported by the integrated drive
control of the SIMATIC Drive Controller:
•
Free function blocks (FBLOCKS)
•
SINAMICS Web server
•
SIMOTION-specific or SINUMERIK-specific DRIVE-CLiQ components (e.g. TM17 Terminal
Modules, HLA Hydraulic Drive, CX32-2 Controller Extension, NX10.3/NX15.3 Numeric
Control Extensions)
•
Expansion boards, e.g. TB30, CBE20, CBE30-2
•
Hardware and functions not supported by SINAMICS Startdrive, see
(https://support.industry.siemens.com/cs/ww/en/view/109761180)
In addition, not all licensed functions and Technology Extensions (TEC) of a SINAMICS S120
CU320-2 are available to the SINAMICS Integrated. For example, the High Output Frequency
function for high output frequencies >550Hz is not available.
NOTE
Use of SINAMICS S120 CU320-2 Control Units
Additional CU320-2 Control Units on the SIMATIC Drive Controller have the full range of
functions compared with SINAMICS Integrated.
31
Product overview
3.6 Firmware functions of SINAMICS Integrated
SIMATIC Drive Controller
Equipment Manual, 11/2022, A5E46600370-AC
