Siemens SIMATIC S7-1500T User Manual

Wiring
4.3 Terminal and block diagrams
CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
102 Manual, 09/2016, A5E35306440-AB
Technical characteristics of the outputs
The following table shows an overview of the technical characteristics of the individual
outputs.
Frequency range
(period duration)
DQ0 to DQ7
DQ8 to DQ15
High-speed output
(0.1 A) activated
High-Speed output
(0.1 A) deactivated
Standard output
max. 100 kHz max. 10 kHz max. 100 Hz
max. 0.1 A
max. 0.5 A
max. 0.5 A
Switching to P potential /
sink output
Switching to P potential Switching to P potential
Accuracy of
the pulse
duration
10 to <= 100 kHz (100 to >
= 10 µs)
±100 ppm ±2 µs --- ---
100 Hz to <10 kHz (10 ms
to > 100 µs)
±100 ppm ±10 µs with
load > 0.1 A
±100 ppm ±20 µs with
load ≥ 2mA
10 to < 100 Hz (0.1 s to
> 10 ms)
±100 ppm ±100 µs with
load > 0.1 A
±100 ppm ±200 µs with
load ≥ 2mA
1 to <10 Hz (1 to > 0.1 s) ±150 ppm ±2 µs ±150 ppm ±10 µs with
load > 0.1 A
±150 ppm ±20 µs with
load ≥ 2mA
±150 ppm ±100 µs with
load > 0.1 A
±150 ppm ±200 µs with
load ≥ 2mA
0.1 to < 1 Hz (10 to >1 s) ±600 ppm ±2 µs ±600 ppm ±10 µs with
load > 0.1 A
±600 ppm ± 20 µs with
load ≥ 2mA
±600 ppm ±100 µs with
load > 0.1 A
±600 ppm ±200 µs with
load ≥ 2mA
Minimum
pulse dura-
tion
--- 2 µs 20 µs with load > 0.1 A
40 µs with load ≥ 2 mA
100 µs with load > 0.1
A
200 µs with load ≥ 2
mA
