Parameters/address space
5.7 Parameters of the digital on-board I/O
CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
114 Manual, 09/2016, A5E35306440-AB
Configurable parameters and default settings for outputs
Table 5- 11 Configurable parameters for outputs
Parameters
1)
Value range
Default
Reconfiguration in RUN
Diagnostics
• Missing
supply voltage L+
Yes/No No Yes
Reaction to CPU STOP
When the digital output is controlled by a
technology channel (HSC, PTO or PWM),
this parameter is not effective. In this case
the technology channel specifies the reac-
tion of the digital output to CPU STOP.
• Turn off
• Keep last value
• Output substitute value 1
Turn off Yes
1)
All parameters can be set channel-selective
