Siemens SIMATIC S7-1500T User Manual

Analog value processing
C.3 Representation of input ranges
CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
Manual, 09/2016, A5E35306440-AB
183
Table C- 12 Resistance-type thermometer Pt 100 Climate
Pt 100 Climate/
in °C
(1 digit = 0.01 °C)
Values
Pt 100 Climate/
in °F
(1 digit = 0.01 °F)
Values
Range
dec.
hex.
dec.
hex.
> 155.00
32767
7FFF
> 311.00
32767
7FFF
Overflow
155.00
:
130.01
15500
:
13001
3C8C
:
32C9
311.00
:
266.01
31100
:
26601
797C
:
67E9
Overrange
130.00
:
-120.00
13000
:
-12000
32C8
:
D120
266.00
:
-184.00
26600
:
-18400
67E8
:
B820
Nominal range
-120.01
:
-145.00
-12001
:
-14500
D11F
:
C75C
-184.01
:
-229.00
-18401
:
-22900
B81F
:
A68C
Underrange
< -145.00
-32768
8000
< -229.00
-32768
8000
Underflow
Table C- 13 Resistance-type thermometer Ni 100 standard
Ni 100
Standard
in °C
(1 digit =
0.1 °C)
Values
Ni 100
Standard
in °F
(1 digit =
0.1 °F)
Values
Ni 100
Standard
in K
(1 digit =
0.1 K)
Values
Range
dec.
hex.
dec.
hex.
dec.
hex.
> 295.0
32767
7FFF
> 563.0
32767
7FFF
> 568.2
32767
7FFF
Overflow
295.0
:
250.1
2950
:
2501
B86
:
9C5
563.0
:
482.1
5630
:
4821
15FE
:
12D5
568.2
:
523.3
5682
:
5233
1632
:
1471
Overrange
250.0
:
-60.0
2500
:
-600
9C4
:
FDA8
482.0
:
-76.0
4820
:
-760
12D4
:
FD08
523.2
:
213.2
5232
:
2132
1470
:
854
Nominal range
-60.1
:
-105.0
-601
:
-1050
FDA7
:
FBE6
-76.1
:
-157.0
-761
:
-1570
FD07
:
F9DE
213.1
:
168.2
2131
:
1682
853
:
692
Underrange
< -105.0
-32768
8000
< -157.0
-32768
8000
< 168.2
32768
8000
Underflow
