Off Delay Timer
4.1 Introduction
Getting Started - Advanced
32 Training Documents, 09/2007, A5E01469795B
Procedure
In the next pages, we will work through these steps together to implement the off-delay timer
safely.
1. First, load the complete latching circuit
from our first example from the hard disk.
2. Then, save the example under a new
name on the hard disk.
3. We will then work together to complete
the off-delay timer with comments.
4. Finally, we will test the program together.
/HWಬVJHWWRZRUN
