Siemens Simatic S7-400

PROFINET
6.5 System status lists for PROFINET IO
S7-400 Automation System, CPU Specifications
Manual, 10/2006, 6ES7498-8AA04-8BA0
6-9
SSL-ID PROFINET IO PROFIBUS DP Applicability
W#16#4C91 Yes
Parameter adr1 changed
Yes, internal interface
No, external interface
Module status information of a module
attached to an external DP or PN
interface using the start address
W#16#0D91 Yes
Parameter adr1 changed
No, external interface
Yes, internal interface
No, external interface
Module status information of all modules
in the specified rack/station
W#16#0696 Yes, internal interface
No, external interface
No Module status information of all
submodules on an internal interface of a
module using the logical address of the
module, not possible for submodule 0
(= module)
W#16#0C96 Yes Yes, internal interface
No, external interface
Module status information of a
submodule using the logical address of
this submodule
W#16#xy92 No
Replacement: SSL-ID
W#16#0x94
Yes Rack/stations status information
Replace this system status list with the
system status list with ID W#16#xy94 in
PROFIBUS DP, as well.
W#16#0x94 Yes No Rack/station status information
Detailed Information
For detailed descriptions of the individual system status lists, refer to the manual System
Software for S7-300/400 System and Standard Functions
.
