Communication
4.3 S7 connections
S7-400 Automation System, CPU Specifications
4-18 Manual, 10/2006, 6ES7498-8AA04-8BA0
4.3 S7 connections
4.3.1 Communication path of an S7 connection
An S7 connection is established as a communication channel when S7 modules
communicate with one another.
Note
Global data communication, point-to-point connection via CP 341, PROFIBUS DP,
PROFINET CBA, PROFINET IO, Web and SNMP require no S7 connections.
Every communication link requires S7 connection resources on the CPU for the entire
duration of this connection.
Thus, every S7 CPU provides a specific number of S7 connection resources. These are
used by various communication services (PG/OP communication, S7 communication or
S7 basic communication).
Connection points
An S7 connection between modules with communication capability is established between
connection points. The S7 connection always has two connection points, one active and one
passive:
● The active connection point is assigned to the module that establishes the S7 connection.
● The passive connection point is assigned to the module that accepts the S7 connection.
Any module that is capable of communication can thus act as an S7 connection point. At the
connection point, the established communication link always uses one S7 connection of the
module concerned.
Transition point
If you use the routing functionality, the S7 connection between two modules capable of
communication is established across a number of subnets. These subnets are
interconnected via a network transition. The module that implements this network transition
is known as a router. The router is thus the point through which an S7 connection passes.
Any CPU with a DP or PN interface can be the router for an S7 connection. The number of
S7 connections limits the number of routing connections.
