Structure of a CPU 41x
2.3 Status and error displays
S7-400 Automation System, CPU Specifications
Manual, 10/2006, 6ES7498-8AA04-8BA0
2-9
Error and Fault Displays and Special Characteristics
The three LEDs INTF, EXTF and FRCE on the front panel of the CPU indicate errors and
special features in user program execution.
Table 2-4 Possible statuses of the INTF, EXTF and FRCE LEDs
LED
INTF EXTF FRCE
Meaning
H x x An internal error was detected (programming or parameter assignment
error) or the CPU is performing a CiR.
x H x An external error was detected (in other words, the cause of the error is
not on the CPU module).
x x H A force job is active.
x x B
2 Hz
Node flash test function.
H = LED is lit; B = LED flashes with the specified frequency; x = LED status is irrelevant
The LEDs BUS1F and BUS5F indicate errors on the MPI/DP, PROFIBUS DP and
PROFINET IO interfaces.
Table 2-5 Possible states of the BUS1F and BUS5F LEDs
LED Meaning
BUS1F BUS5F
H x An error was detected on the MPI/DP interface.
x x An error was detected on the PROFIBUS DP interface.
x H An error was detected on the PROFINET IO interface.
CPU is DP master: One of more slaves on the PROFIBUS DP interface
are not responding.
B x
CPU is DP slave: CPU is not addressed by the DP master.
H = LED is lit; B = LED flashes; x = LED status is irrelevant
Error and Fault Displays and Special Characteristics
The CPUs 41x-3 also feature the IFM1F LED. This LED indicates problems relating to the
memory submodule interface.
Table 2-6 Possible states of the IFM1F LED
LED
IFM1F
Meaning
H An error was detected on memory submodule interface.
B CPU is DP master: One of more slaves on the PROFIBUS DP interface module
inserted in the receptacle are not responding.
CPU is DP slave: CPU is not addressed by the DP master.
H = LED is lit; B = LED flashes; x = LED status is irrelevant
