Communication
4.1 interfaces
S7-400 Automation System, CPU Specifications
Manual, 10/2006, 6ES7498-8AA04-8BA0
4-5
Properties
2 x RJ45 Connector design
Switch with 2 ports
Switch with Store and Forward procedures
Max. 10/100 Mbps Transmission speed
Autosensing
Autocrossing
Autonegotiation
Media Twisted Pair Cat5
Note
Networking PROFINET Components
Full duplex mode with 100 Mbps is mandatory for PROFINET IO.
Reference
● For further information on PROFINET, refer to
PROFINET System Description
● For detailed information about Ethernet networks, network configuration and network
components refer to the
SIMATIC NET Manual: Twisted-Pair and Fiber Optic Networks
,
available under article ID 8763736 at http://support.automation.siemens.com.
●
Component Based Automation, Commissioning SIMATIC iMap Systems - Tutorial,
Article ID 18403908
Further information about PROFINET: http://www.profinet.com
